\[f\left(A\right)=A^{n}+a_{n-1}A^{n-1}+\cdots+a_{1}A^{1}+a_{0}I=0\]

所以有 \(A^{n}=-a_{n-1}A^{n-1}-a_{n-2}A^{n-2}-\ldots-a_{1}A^{1}-a_{0}I\)

\(e^{At}\) 定义中,用上述的方法可以消去 \(A\)\(n\)\(n\) 以上的幂次项。

因此

\[e^{At}=I+At+\frac{1}{2!}A^{2}t^{2}+\ldots+\frac{1}{n!}A^{n}t^{n}+\ldots=\alpha_{n-1}\left(t\right)A^{n-1}+\alpha_{n-2}\left(t\right)A^{n-2}+\ldots+\alpha_{1}\left(t\right)A+\alpha_{0}\left(t\right)I\]

25、简述李雅普诺夫第一法判断系统稳定性的基本思路

李雅普诺夫第一法又称间接法,是通过系统状态方程的解来判别系统的稳定性。对于线性定常系统,只需解出特征方程的根即可作出稳定性判断。对于非线性不很严重的系统,则可通过线性化处理,取其一次近似得到线性化方程,然后再根据其特征根来判断系统的稳定性。

26、\(\dot{x}=Ax+Bu,y=Cx\),用全维状态观测器实现状态反馈,简述其系统闭环的状态方程以及闭环极点设计可分离性。

解析:对 \(\dot{x}=Ax+Bu,y=cx\),用全维状态观测器实现状态反馈为

图:26BUFF控制简答题库_p058_fig1

其系统闭环的状态方程

\[\begin{bmatrix}\dot{x}\\\dot{\hat{x}}\end{bmatrix}=\begin{bmatrix}A&BK\\GC&A-GC+BK\end{bmatrix}\begin{bmatrix}x\\\hat{x}\end{bmatrix}+\begin{bmatrix}B\\B\end{bmatrix}v \ , \quad y=\begin{bmatrix}C&0\end{bmatrix}\begin{bmatrix}x\\\hat{x}\end{bmatrix}\]

闭环极点设计的分离性:设状态估计误差 \(\tilde{x}=x-\hat{x}\),引入等效变换:

$$\begin{bmatrix}x\\tilde{x}\end{bmatrix}=\begin{bmatrix}I&0\I&-I\end{bmatrix}\begin{bmatrix}x\\hat{x}\end{bmatrix}=\begin{bmatrix}x\x-\hat{x}\end{bmatrix} \ ,\ 令变换矩阵为:T=\begin{bmatrix}I&0\I&-I\end{bmatrix} \ ,则 T^{-1}=T \ 。变换后系统
